The valve body and bonnet are made of WCB cast steel compliant with ASTM A216 standard, featuring excellent mechanical strength, toughness and castability. It can stably withstand a nominal pressure of PN16 (equivalent to Class 150) and adapt to a wide operating temperature range from -29℃ to +425℃. Adopting a floating straight-through structure, the valve only requires a 90-degree rotation to open and close with low operating torque. It is suitable for various media including natural gas, liquefied petroleum gas (LPG), crude oil, steam, water, acid-base solutions and other fluids.
Applicable Medium |
WOG Steam |
Connection |
Flanged End |
Interface Size |
DN20-DN600 |
Structure |
BALL |
Media Temperature |
Low Temperature, Medium Temperature, Normal Temperature |
Place of Origin |
Tianjin, China |
Working Temperature |
0~80°C |
Customization Supported |
OEM, ODM, OBM |
Brand |
TF |
Model (Number) |
Q41F-16C |
Connection Dimensions |
4 in, 1 in, 3/4 In, 2 in, 3 in 1/2’’ 1/4’’ |
Warranty Period |
18 Months |
For the maximum pipe size |
24inchDN600 |
Valve Body |
CF8 SS304 CF8M |
Operating Temperature Range |
-20 ℃;-120℃ |
Working Air Pressure |
100 psi |
Sealing Material |
PTFE |
Size |
DN20-DN600 3/4 "-24" |
Pressure |
PN10 PN16 1.0MPa 1.6MPa Class150 Class300 Class600 |
Valve Body Material |
WCB |
Seal |
Soft Seal |
Certificate |
CE IS09001 ISO14001 IS045001 |
Packaging and Shipping Information
Gross Weight per Unit Product |
10,000 Kilograms (or 10,000 kg) |
Package Size per Unit |
15X20X15 Centimeters |
MOQ:1
