The flanged worm gear butterfly valve is a high-performance valve that achieves opening and closing control through a worm gear reduction mechanism. It is installed in pipeline systems using a flanged connection method. Its core component is a disc-shaped valve plate, which is connected to the worm gear transmission mechanism via a valve stem. The valve plate rotates around its own axis (within the range of 0°~90°) inside the valve body, enabling the shut-off of media or regulation of flow rate. It is applied in industries such as water supply and drainage, metallurgy, energy systems, and light industry & textile, where the temperature is below 120-150℃ and the nominal pressure is less than 1.6MPa.
Applicable Medium |
Water |
Flowing Medium |
Water |
Interface Size |
DN50-600 |
Structure |
Butterfly |
Medium Temperature |
Low Temperature, Medium Temperature, Normal Temperature |
Place of Origin |
Tianjin, China |
Application |
/ |
Customization Supported |
OEM, ODM, OBM |
Power |
Manual |
Model (Number) |
D341X-16/10Q |
Brand |
TF |
Warranty Period |
18 Months |
Medium Temperature |
T<80 |
Valve Body Material |
Ductile Iron QT450 Material |
Connection |
Flanged End |
Warranty |
18 Months |
Valve Body Material |
Ductile Iron QT450 Material |
Disc |
Ductile Iron QT450 Material |
Valve Stem |
Stainless Steel CF8 SS304 |
Seat |
EPDM / PTFE / NBR |
Connection |
Flanged End Wafer |
Standard |
ISO |
Packaging and Shipping Information
Gross Weight per Unit Product |
10,000 Kilograms (or 10,000 kg) |
Package Size per Unit |
15 x 7 x 10 Centimeters (or 15×7×10 cm) |
Minimum Order Quantity：1
