1. Compact structure, reasonable design, good valve rigidity, smooth channel and small flow resistance coefficient.
2. The sealing surface is made of stainless steal and cemented carbide, with long service life.
3.Flexible graphite packing, reliable sealing, light and flexible operation.
4. The driving mode is divided into pneumatic, electric, pneumatic and gear transmission; The structural types are elastic wedce singlevalve, rigid wedge single ram and double ram.
5. it is widely used in oil, water and steam pipelines of petroleum, chemical and thermal power plants as opening and closing devices toconnect or cut off the medium in the pipeline.
Applicable Medium |
Water |
Interface Size |
DN 40 - DN1200 |
Power |
Manual |
Valve Structure |
Gate Valve |
Medium Temperature |
-10℃~80℃ |
Place of Origin |
Tianjin, China |
Customization is supported |
OEM, ODM, OBM |
Valve Model |
Z45X |
Brand |
TF |
Warranty Period |
18 Months |
Size |
DN40-DN1200 1.5"-48" |
Pressure |
PN10 PN16 1.0MPa1.6MPa Class150 |
Certificate |
CE IS09001 ISO14001 IS045001 |
Valve Body Material |
Ductile Iron QT450 Material |
Valve Stem |
Stainless Steel Material |
Sealing Ring |
EPDM / NBR |
Connection Structure |
Flanged End Wafer |
Seal |
Soft Seal |
Packaging and Shipping Information
Gross Weight per Unit Product |
10,000 Kilograms (or 10,000 kg) |
Package Size per Unit |
15 x 7 x 10 Centimeters (or 15×7×10 cm) |
Minimum Order Quantity：1
